Cost-Effectiveness Foldable Container Barracks Military Camp
Environmental Protection Sustainability
Description
Foldable container barracks can be quickly unfolded or folded
within a short time, significantly reducing the time required for
deployment and withdrawal. In military operations, time is often a
crucial factor, so the ability to rapidly adjust the location or
size of barracks is crucial for strategic and tactical flexibility.
Foldable container barracks are typically lightweight and easy to
transport due to their structural characteristics. This means they
can be rapidly deployed using various modes of transportation, such
as trucks, aircraft, and helicopters, to meet needs in remote or
emergency situations.
Foldable container barracks can adapt to various environmental
conditions, including harsh weather and terrain. Their structural
design and material choice often consider durability and resistance
to wind and rain, ensuring stable living conditions in diverse
environments.
Many foldable container barracks feature a modular design, meaning
they can be combined and expanded according to needs. This
flexibility allows them to adapt to different sizes of troops and
varying accommodation requirements.
While the initial investment in foldable container barracks may be
higher, they typically offer good cost-effectiveness when
considering their lifespan, reusability, and maintenance costs.
Additionally, their rapid deployment and withdrawal characteristics
can save significant labor and time costs.
Besides serving as accommodation facilities, foldable container
barracks can also be used for other purposes, such as temporary
storage, medical facilities, and command posts. This versatility
makes them highly valuable in military operations.
Some modern foldable container barracks employ environmentally
friendly materials and energy-saving designs, aligning with
sustainability requirements. This helps reduce environmental impact
and complies with green procurement policies of many countries and
militaries.
| Standard Quick Assembly Container House Datasheet |
Product Specification:
3-meter standard container | Length(mm) | 5950(5730) |
| Width(mm) | 3000(2800) |
| Height(mm) | 2800(2500) |
| Center column | |
| Roof | Flat roof, free drainage |
| Number of floors | ≤3 |
| Design parameters | Service life | 5-8 years |
| Ground live load | 1.8KN/㎡ |
| Roof live load | 0.5KN/㎡ |
| Wind load | 0.6KN/㎡ |
| Seismic degree | 8 |
| Structural | corner column | galvanized cold rolled section steel, t=2.3mm, material Q235B |
| roof main beam | galvanized cold rolled section steel, t=2.3mm, material Q235B |
| roof sub-beam | Galvanized square steel 5*5, t=1.5mm, radian galvanized square
steel 4*6t= 1.2mm material Q235B |
| floor main beam | galvanized cold-rolled section steel, t=2.3mm, material Q235B |
| floor sub-beam | galvanized square steel 4*8 (5), galvanized square steel 8*8 (4)
material Q235B |
| Paint | Graphene Powder spraying (Electrostatic spraying) |
| Roof | Roof panel | 0.40mm thick color steel plate, color white gray |
| Ceiling | 0.25mm thick 811 ceiling, color white gray |
| Floor | Decorative surface | |
| basic floor | 18mm sanding board |
| Wall | Thickness | 50mm thick color steel glass fiber sandwich board; The outer and
inner plates are made of 0.3mm aluminum plated zinc color steel
plate |
| Heat preservation | 50mm thick glass silk wool, bulk weight ≥60kg/m³, combustion
performance is class A non-combustible |
| Color | white gray PE coating |
| Door | Spec(mm) | Width X height =920*2030 common door |
| Material | Steel door |
| Window | Spec(mm) | Front window: width X height =920*1200; Rear window (standard) :
width X height =920*1200; |
| Frame | Plastic steel window single glass |
| Glass | common |
| Electricity | Voltage | 220V~250V |
| Wire | input power wire is 4 square, AC wire is 4 square, socket wire is
2.5 square, lighting switch wire is 1.5 square |
| Circuit breaker | High break Miniature Circuit breaker (32A) |
| Lamp tube | Two sets of circular LED fluorescent lamps |
| Socket | 3 five-hole socket 10A, 1 three-hole air conditioning socket 16A |
Company introduction
As a wholly-owned subsidiary of Wujiang Saima (established in
2005), Suzhou Stars Integrated Housing Co., Ltd. focuses on foreign
trade. As one of the most professional prefabricated house
manufacturers in south-east China, we provide customers with all
kinds of integrated housing solutions.
Equipped with complete production lines, including sandwich panel
production machines and steel structure production line, with 5000
square meter workshop and professional staff, we already built
long-term business with domestic giants like CSCEC and CREC. Also,
based on our export experience in the past years, we are furthering
our steps to global customers with best product and service.
As a supplier to overseas customers all over the world, we are very
familiar with the manufacturing standards of various countries,
such as European standards, American standards, Australian
standards, and so on. We have also participated in the construction
of many large-scale projects, such as recent 2022 Qatar World Cup
camping construction.
