In the realm of temporary accommodations, our modular container
steel structure camp offers versatility, durability, and
portability. Designed to be adaptable to various scenarios, this
camp provides a robust and reliable solution for temporary housing
needs in different environments.
Key Features:
Versatility: Our modular container camp is designed to be adaptable
to multiple scenarios, including disaster relief efforts,
construction sites, remote work camps, and temporary housing
projects.
Sturdiness: Constructed with high-quality steel materials, our camp
offers exceptional structural strength and stability, ensuring a
safe and secure living environment for occupants.
Durability: Engineered to withstand harsh environmental conditions,
our camp is resistant to corrosion, erosion, and wear, ensuring
long-lasting performance in challenging environments.
Portability: Featuring a modular and detachable design, our camp
can be easily transported to different locations and reassembled as
needed, providing flexibility and convenience for temporary housing
solutions.
Customization: Our camp can be customized to meet specific
requirements, including layout configurations, interior amenities,
and additional features tailored to the needs of occupants.
Ease of Assembly: With prefabricated components and simple assembly
procedures, our camp can be quickly set up on-site, minimizing
downtime and disruption to operations.
Cost-Effectiveness: Offering a cost-effective alternative to
traditional construction methods, our camp reduces overall project
expenses while delivering exceptional performance and value.
Applications:
Disaster relief shelters
Construction site accommodations
Remote work camps
Temporary housing for events and festivals
Military operations and field deployments
Conclusion:
Our versatile, sturdy, and durable modular container steel
structure camp provides a reliable solution for temporary housing
needs in various scenarios. With its adaptability, sturdiness,
portability, customization options, and cost-effectiveness, this
camp offers a flexible and convenient accommodation solution for a
wide range of applications, ensuring comfort, safety, and
satisfaction for occupants.
| Standard Quick Assembly Container House Datasheet |
Product Specification:
3-meter standard container | Length(mm) | 5950(5730) |
| Width(mm) | 3000(2800) |
| Height(mm) | 2800(2500) |
| Center column | |
| Roof | Flat roof, free drainage |
| Number of floors | ≤3 |
| Design parameters | Service life | 5-8 years |
| Ground live load | 1.8KN/㎡ |
| Roof live load | 0.5KN/㎡ |
| Wind load | 0.6KN/㎡ |
| Seismic degree | 8 |
| Structural | corner column | galvanized cold rolled section steel, t=2.3mm, material Q235B |
| roof main beam | galvanized cold rolled section steel, t=2.3mm, material Q235B |
| roof sub-beam | Galvanized square steel 5*5, t=1.5mm, radian galvanized square
steel 4*6t= 1.2mm material Q235B |
| floor main beam | galvanized cold-rolled section steel, t=2.3mm, material Q235B |
| floor sub-beam | galvanized square steel 4*8 (5), galvanized square steel 8*8 (4)
material Q235B |
| Paint | Graphene Powder spraying (Electrostatic spraying) |
| Roof | Roof panel | 0.40mm thick color steel plate, color white gray |
| Ceiling | 0.25mm thick 811 ceiling, color white gray |
| Floor | Decorative surface | |
| basic floor | 18mm sanding board |
| Wall | Thickness | 50mm thick color steel glass fiber sandwich board; The outer and
inner plates are made of 0.3mm aluminum plated zinc color steel
plate |
| Heat preservation | 50mm thick glass silk wool, bulk weight ≥60kg/m³, combustion
performance is class A non-combustible |
| Color | white gray PE coating |
| Door | Spec(mm) | Width X height =920*2030 common door |
| Material | Steel door |
| Window | Spec(mm) | Front window: width X height =920*1200; Rear window (standard) :
width X height =920*1200; |
| Frame | Plastic steel window single glass |
| Glass | common |
| Electricity | Voltage | 220V~250V |
| Wire | input power wire is 4 square, AC wire is 4 square, socket wire is
2.5 square, lighting switch wire is 1.5 square |
| Circuit breaker | High break Miniature Circuit breaker (32A) |
| Lamp tube | Two sets of circular LED fluorescent lamps |
| Socket | 3 five-hole socket 10A, 1 three-hole air conditioning socket 16A |
Company introduction
As a wholly-owned subsidiary of Wujiang Saima (established in
2005), Suzhou Stars Integrated Housing Co., Ltd. focuses on foreign
trade. As one of the most professional prefabricated house
manufacturers in south-east China, we provide customers with all
kinds of integrated housing solutions.
Equipped with complete production lines, including sandwich panel
production machines and steel structure production line, with 5000
square meter workshop and professional staff, we already built
long-term business with domestic giants like CSCEC and CREC. Also,
based on our export experience in the past years, we are furthering
our steps to global customers with best product and service.
As a supplier to overseas customers all over the world, we are very
familiar with the manufacturing standards of various countries,
such as European standards, American standards, Australian
standards, and so on. We have also participated in the construction
of many large-scale projects, such as recent 2022 Qatar World Cup
camping construction.
